Diesel Three-wheeled Transport Vehicle
Powerful power: The diesel engine has high torque at low speed, can easily handle 45° slopes, and its heavy-load climbing ability is 30% higher than that of gasoline vehicles.
Strong load-bearing capacity: double-beam frame + thickened steel plate structure, rated load of 2-3 tons, suitable for bulk transportation of sand, gravel, building materials, etc.
Durable and durable: spark plug-free design, low failure rate, simple maintenance, normal service life of 5-8 years
Wide application scenarios: Modular design such as hydraulic dump and closed cargo compartment can be used in agriculture, engineering, sanitation and other fields.
product description
Core advantages of diesel three-wheeled transport vehicles
Super strong load-bearing performance
Adopting double-beam weighted frame structure (such as Wuzheng K50's 50 * 100 double-layer beam, Laizhou LX-5's double double-beam design), the frame steel plate thickness is more than 3mm, and the maximum load can reach 2 tons after 50,000 kilometers of road test
Equipped with engineering compartments (such as three-door design, U-beam bottom plate), the ground clearance is only 75cm, and the loading and unloading efficiency is increased by 40%
Both power and energy saving
Equipped with National IV electronic injection diesel engine (such as Changzhou 18 horsepower model), the low-speed torque is 30% higher than that of gasoline models, and the climbing grade in mountainous areas reaches 45°
Fully intelligent electronic control technology (ECU fuel injection system), fuel consumption is reduced by 15%-20%, Endurance up to 12 hours
Professional engineering configuration
Three-level hydraulic dump system, supports 180° self-unloading, triple protection of hydraulic oil top filter, durability increased by 50%
Optional vacuum power brake, double shock-absorbing seat, adapt to the bumpy road conditions of construction sites
Applicable scenarios and functional expansion
Construction: transport of sand and gravel, concrete (leak-proof design of the carriage), construction waste (thickened baffle to prevent wear)
Agricultural logistics: grain transportation during busy farming season, feed/feces transfer in farms (enclosed carriage optional)
Municipal maintenance: equipped with a sprinkler module, can be switched to a sanitation operation vehicle
Best after-sale
Our after-sales service team is always ready to serve you to ensure that there are no problems during your use
State of the art technology
Our technical team will use the highest enthusiasm to manufacture the equipment you need
the best service
Our sales team will provide you with warm and professional service to make your career more prosperous
Jining Flying Rain Mechanical & Electrical Technology Co., Ltd. specializes in producing advanced machinery, including prestressed slab, purlin, lintel & wood forming machines, light wallboard equipment, cranes (truck-mounted & crawler types), sweepers, etc. Our designs are scientific, durable, and user-friendly, ensuring fast, high-quality production with cost savings and long service life, enhancing clients' competitiveness and profitability.
We prioritize quality, service, and customer satisfaction. Rapid parts delivery, 24/7 customer support, and lifelong maintenance ensure seamless operations. Our "customer-centric" approach offers comprehensive services, with "service as the core" to deliver maximum value. Quality focus and all-round customer care are our hallmarks. High-quality products, impeccable services, and competitive pricing are our principles. We strive for excellence in every aspect, partnering with clients for mutual success based on integrity, quality, and service.
You may be interested
We recommend the following equipment that you may be interested in
mini-excavator
Small excavators have become the ideal choice for urban construction and complex construction environments with their advantages of strong flexibility, wide operating range, convenient transfer and high cost effectiveness.
Mine transport vehicle
Due to its strong load capacity, robustness to adapt to harsh working conditions and high transportation efficiency, the mining truck has become an indispensable important equipment in mining.
Crawler transporter
Tracked transporters offer unparalleled transport advantages in difficult terrain and harsh environments thanks to their excellent ground mobility, strong traction and stability.
hydraulic aerial cage
With its excellent lifting capacity, stable working platform and wide range of work, the aerial work vehicle provides a safe, efficient and flexible solution for aerial work.
electric forklift
With its advantages of zero emission, low noise, easy operation and high energy efficiency, electric forklifts have become the preferred equipment for green handling in the field of modern warehousing and logistics.
Diesel three-wheeled transporter
With its powerful loading capacity, flexible driving performance and the long-lasting power provided by diesel engines, diesel three-wheeled transporters are highly efficient tools in short-haul and heavy-duty operations.
precautions for product use
Please pay attention to the following precautions in use
Load control
Overloading is strictly prohibited: the rated load limit is 70% of the vehicle design (e.g. the actual load of a 2-ton vehicle does not exceed 1.4 tons). Overloading will accelerate the deformation of the frame. It has been measured that for every 500kg of overload, the life of the leaf spring is shortened by 40%
Cargo distribution: The loading center of gravity should be close to the front 1/3 of the car to avoid backward tilt and steering loss of control
Diesel engine cold start protection
Preheating requirements: When the ambient temperature is below 5°C, you need to idle and preheat for 3-5 minutes before starting to avoid cylinder wear
Fuel selection: Use -10# or lower diesel (in winter) to prevent wax from clogging the oil circuit
Hydraulic dump system operation
Tipping bucket limit: dump angle does not exceed 180° to avoid hydraulic cylinder overload and breakage
Maintenance cycle: replace hydraulic oil every 200 hours of operation, clean filter element monthly to prevent impurities from clogging the valve body
Braking system management
Heavy load braking distance: When the load is 2 tons, the braking distance is 60% longer than that of an empty vehicle. It is necessary to predict the road conditions in advance
Inspection focus: Adjust the brake pad clearance every 500 kilometers (standard 0.3-0.5mm), and daily inspection is required for mountain operations
Driving rules for complex terrain
Climbing skills: When the slope is greater than 30°, you need to switch to low gear (≤15km/h), and it is forbidden to change gears midway
Muddy roads: Reduce tire pressure to 200kPa to increase grip, and stop driving immediately if the roll exceeds 15°
Long-term out-of-service maintenance
Storage conditions: Park in a dry and ventilated place, with tire pads off the ground to prevent rubber aging
Battery maintenance: Disconnect the negative cable, charge once a month to maintain power, avoid battery vulcanization and ECU data loss
You may want to ask
Jining Feiyu electromechanical technology Co., LTD
What are the core advantages of diesel three-wheelers over gasoline vehicles?
High torque at low speed: The diesel engine can output peak torque at 1500-2500rpm, and the heavy-load climbing ability is improved by 30%
High fuel economy: Fuel consumption is 20%-30% lower under the same load, and the cruising range can reach 400-600 kilometers
High durability: Diesel has a high flash point (＞55℃), no spark plug design, and the failure rate is 40% lower than that of gasoline vehicles
How much can a vehicle with a nominal load of 2 tons actually carry?
Safe load: It is recommended not to exceed 70% of the nominal value (i.e. 1.4 tons). Overloading will result in:
Shortening the life of leaf springs by 40%
Increasing the braking distance by 60%
Road condition impact: Continuous slopes (＞15°) should reduce the load by 30%
What are the taboos in operating hydraulic dump systems?
Forbidden to unload with full bucket: the cargo compartment materials must be loose and non-sticky, and forced unloading may cause the hydraulic cylinder to burst
Limit protection: the bucket tipping angle is ≤180°, and over-limit operation may break the hydraulic pipeline
Maintenance cycle: replace the hydraulic oil every 200 hours, and clean the filter element every month
What to do if starting is difficult in winter?
Fuel treatment: Replace with -10# or -20# diesel, add diesel anticoagulant (ratio 1:1000)
Preheating operation: Idle preheating for 3-5 minutes before starting a cold car, and the oil pan can be heated at extremely low temperatures
Circuit inspection: Battery voltage must be ≥12.6V, and aging batteries must be replaced in time
How to extend clutch life?
Operation specification: When shifting gears, completely depress the clutch pedal, and semi-clutch climbing is prohibited
Load matching: When starting in 1st gear, the load is ≤1 ton, and 2 tons of load need to start in 2nd gear
Wear warning: When the pedal free travel is less than 15mm, it needs to be adjusted immediately
What special modifications are needed for operations in mountainous areas?
Power enhancement: add a turbocharger to improve low-speed torque output
Braking system: modify the vacuum-assisted brake, and use a water sprayer to prevent the brake from overheating
Chassis protection: add 63-type leaf spring shock absorbers, and replace the tires with 8-layer puncture-proof models
How to prevent deformation of the cargo compartment floor?
Structural design: Use U-beam bottom plate (thickness ≥ 2mm), which has 50% higher bending strength than flat plate
Loading specification: Place heavy objects in front to avoid concentrated force on a single point
Remedial measures: Check the bottom plate weld every 6 months and repair cracks in time
What is the reason why diesel engines emit black smoke?
Combustion problem: air filter blockage (replacement cycle ≤ 200 hours) or poor atomization of the injector
Abnormal load: the load exceeds the current gear capacity, and it is necessary to downshift or reduce the load
Oil quality problem: the use of inferior diesel leads to carbon deposits, and the oil circuit needs to be cleaned
